Str1138
Code name (Unique Key)
Str1138
Type of structural unit
Vertical timber reinforcement system of masonry
List of related timber evidence
Chase in a wall
Hole
Location code
Space code
Position in the space
Vertical reinforcement system in the east wall of Corridor Y and the west wall of the Pithoi Room.
Preserved height
1.00
Preserved length
6.40
Preserved width
1.10
Number of vertical timber pairs
at least four
Distance of vertical timber elements / pairs (between and from the ends of the wall)
0.50-0.60
Presence of stone bases for the vertical timbers
No
Presence of other transversal horizontal timber along the height of the wall
Yes
Distance of 1st longitudinal horizontal timber from the ground
ca 1.20m above current ground level
Presence of second longitudinal horizontal timber (level of lintels of skylights)
Yes
Distance of second longitudinal horizontal timber from the ground
ca 1.85m above current ground level
Type of masonry of the wall
Rubble masonry
Current state of preservation
Medium
Method of documentation
On site
General description of the vertical timber reinforcement system
Vertical reinforcement system in the east wall of Corridor Y and the west wall of the Pithoi Room, preserving the chases for twelve vertical timbers, two horizontal timbers, and one transversal timber
Linked resources
-
First preserved chase for a horizontal timber from the ground, running alon... -
Second preserved chase for a horizontal timber from the ground, running alo... -
Disturbed chase on the wall for a vertical timber of ca 0.20-0.25m diameter... -
Disturbed chase on the wall for a vertical timber of ca 0.17-0.23m diameter... -
Disturbed chase on the wall for a vertical timber of ca 0.15-0.23m diameter... -
Disturbed chase on the wall for a vertical timber... -
Disturbed chase on the wall for a vertical timber... -
Disturbed chase on the wall for a vertical timber of ca 0.15-0.20m diameter... -
Disturbed chase on the wall for a vertical timber of ca 0.15-0.20m diameter... -
Disturbed wall chase for a vertical timber, of which only its north side is... -
A hole 0.55 m deep,at the intersection of horizontal Tim1220 and vertical T... -
Heavily disturbed chase on the wall for a vertical timber... -
Heavily disturbed chase on the wall for a vertical timber of ca 0.15 m diam... -
Heavily disturbed chase on the wall for a vertical timber of ca 0.20 m diam... -
Heavily disturbed chase on the wall for a vertical timber of ca 0.20 m diam...
