Str1137
Code name (Unique Key)
Str1137
Type of structural unit
Vertical timber reinforcement system of masonry
List of related timber evidence
Chase in a wall
Hole
Location code
Space code
Position in the space
Vertical reinforcement system on the south wall of Corridor X
General dimensions of the saved part of the vertical timber reinforcement system
5.00x1.15x1.20
Preserved height
1.20
Preserved length
5.00
Preserved width
1.15
Number of vertical timber pairs
5
Distance of vertical timber elements / pairs (between and from the ends of the wall)
0.55-0.75
Presence of stone bases for the vertical timbers
No
Presence of transversal horizontal timber on the stone base
Unknown
Presence of other transversal horizontal timber along the height of the wall
Yes
Distance of transversal horizontal timber along the height of the wall from the ground
Yes
Distance of 1st longitudinal horizontal timber from the ground
ca. 1.00m from current ground level
Presence of second longitudinal horizontal timber (level of lintels of skylights)
Yes
Distance of second longitudinal horizontal timber from the ground
ca. 1.70m from current ground level
Type of masonry of the wall
Rubble masonry
Current state of preservation
Medium
Method of documentation
On site
General description of the vertical timber reinforcement system
Vertical reinforcement system in the south wall of Corridor X, where the chases for five vertical timbers, two horizontal timbers, and one transversal timber are preserved
Linked resources
-
First preserved chase for a horizontal timber from the ground, running alon... -
Second preserved chase for a horizontal timber from the ground, running alo... -
Disturbed chase on the wall for a vertical timber of ca 0.15m diameter/widt... -
Disturbed chase on the wall for a vertical timber of ca 0.18m diameter/widt... -
Disturbed chase on the wall for a vertical timber of ca 0.15m diameter/widt... -
Disturbed chase on the wall for a vertical timber of ca 0.20m diameter/widt... -
Disturbed chase on the wall for a vertical timber of ca 0.15-0.20m diameter... -
A through-hole at the intersection of horizontal Tim1213 and vertical Tim12...
