Str1122
Code name (Unique Key)
Str1122
Type of structural unit
Vertical timber reinforcement system of masonry
Horizontal timber reinforcement system of masonry
List of related timber evidence
Chase in a wall
Location code
Space code
Position in the space
The lower part of the south retaining wall of the court, reused in a secondary phase, was excavated in 1967. Its north face preserved seven vertical chases, spaced approximately 0.80 m apart, and three horizontal chases, spaced approximately 0.60 m apart, probably associated with a timber frame structure.
Preserved length
5
Number of vertical timber pairs
7
Distance of vertical timber elements / pairs (between and from the ends of the wall)
0.80
Presence of other transversal horizontal timber along the height of the wall
Unknown
Type of masonry of the wall
Rubble masonry
Connection of the vertical timber reinforcement system with surrounding structural units (walls, floor above, polythyra, etc.)
These features are probably associated with a timber-frame structure. Along a preserved length of 5 m, seven vertical chases at intervals of approximately 0.80 m and three horizontal chases at intervals of approximately 0.60 m are visible.
State of preservation when excavated
Good
Current state of preservation
Missing/disappeared
Method of documentation
Bibliographical
General description of the vertical timber reinforcement system
These features are probably associated with a timber-frame structure. Along a preserved length of 5 m, seven vertical chases at intervals of approximately 0.80 m and three horizontal chases at intervals of approximately 0.60 m are visible.
Bibliography
Μυλωνάς 1967, 10-11
Μυλωνάς 1967, πίναξ 4
Μυλωνάς 1967, πίναξ 4
